Guide of facilities - Marina

Wangsan Marina has the latest facilities that can moor 300 yachts and it provides diverse facilities needed for the mooring and maintenance of the yacht.

- Wet & Dry berths(266 wet berths, 34 dry berths)
- Individual water/electricity supply, waste pump-out system
- Fire hydrant, life buoy etc.
- Yacht gas station
- Yacht repair shop(TBD)
- Crane
- Slipways
- Yacht washer area
- Lighthouse
- Building: Area 6,129㎡
- 1st floor : administration office, toilet
- 2nd, 3rd floor : commercial facilities
- Parking lot

Wet berths

266 berths
Composed of 35ft-165ft length of berths
Increased customer convenience by composing docks A-J
Use guidance: Inquire online or offline

Feet (Meter)	35~40 (9~12)	40~60 (12~18)	60~165 (18~50)	total
Dock	A~H	C,I,J	J	266
Number	194	64	8	266

해상계류장 전경이미지 입니다.

Dry berths

75 berths
Dry berths are located outside near wet berths
Use guidance: Inquire online or offline

육상계류장 전경 이미지 입니다.

Water/power supply(Pedestal)

Product of Marina Technologies, Australia
Length 280 x Height 1,120 x Width 250mm
139 pedestals are installed on the floating piers(2 types)

Classification	Berth length	Number(EA)	Remarks
Large size	30~50m	8	Concurrent supply of 380V/220V
Mid and small size	30~50m Less than 18m	131	Supply of 220V

Water/power supply(Pedestal)

Waste pump-out system

Number of installation: 3 places on the floating piers
Use guidance: Free of charge

Waste pump-out system

Fire hydrant, life ring and rope

Safety equipments are installed near wet berths for the safety
Life rings: 45 pieces(28 pieces are located at wet berths and 15 pieces around railings)
Fire hydrants: 28 pieces
Ropes: 45 pieces(Installed together with the life rings – length 27.5m, thickness 8mm)
Use guidance: Use in case of emergency

소화전, 구명환, 밧줄 시설 이미지 입니다.

Yacht gas station

Gas station is operated inside the marina for fuel supply of the yacht
Buried tank(20,000ℓ of gasoline, 30,000ℓ of diesel)
2 lubricators(1 for gasoline, 1 for diesel)
Increased operational convenience by installing hose reel in the lubricator
Use guidance: Call the staff after mooring at the fueling dock(Dock A)

Yacht gas station

Crane

Crane is operated to move the yacht from the sea to the land v.v.
Product of MARINE TRAVELIFT, USA
Maximum of 35tons and 40ft(4.5m width) yacht can be lifted
Use guidance: Available upon advance reservation

크레인 이미지 입니다.

Slipways

The largest and the longest slipways in Korea
Main slipway: Length 103m x Width 50m
Sub slipway: Length 78m x Width 20m
Use guidance: Free for mooring customers, charged for others

경사면(슬립웨이) 이미지 입니다.

Yacht washer area

Provide facility of water supply to wash the yacht
Use guidance : Charges are determine by the operating manager(Do not use cleanser)
Charges apply when using a high pressure washer

세척장 이미지 입니다.

Lighthouse

Automatic lighthouse is operated to guide seamark for the boats
Automatic lighting in case of sunset or fog

등대 이미지 입니다.
